| Name | Parameter |
|
Output signal |
Support RS-485,MODBUS/RTU Protocol |
|
Measurement method |
Ion selection method |
| Range | 0-14PH |
| Accuracy | +-0.1PH |
| Working conditions |
Default 0-65℃ ,<0.2Mpa,other customized |
| Calibration method | Two point calibration |
| Response time | 10 Seconds T90 |
| Temperature compensation | Automatic temperature compensation(PT1000) |
| Power supply | 12 or 24VDC +-10%,10mA |
| Measurement | Diameter 30mm,Length 189mm |
| Level of protection | IP68,Water depth 20 meters |
| Service Lifetime | Sensor 1 year or more,depends |
| Cable Length | 10 meters (Default) ,customized |
| Sensor housing material | POM Customizable |
| Denfence rate | 0.1PH |
| PH Value | Description |
|
<4.5 |
Strongly acidity |
|
4.5-5.5 |
Acidity |
|
5.5-6.5 |
Faintly acidity |
|
6.5-7.5 |
Neutral |
|
7.5-8.5 |
Faintly alkalinity |
|
8.5-9.5 |
Alkalinity |
|
>9.5 |
Strongly alkalinity |
Q1:Are you factory or trading company?
A: We are a manufacture with independent import and export rights.
Q2:How is the quality of your products?
A: Lotus is a manufacturer with production for more than 6 years,We have a complete production
management system and Independent laboratory for testing equipment with a high product
qualification rate .
Q3:How can I get the samples?
A: contact sales to get the samples
Q4:what’s the Minimum order Quantity and Payment?
A1: Payment:EXW,FOB,CFR,CIF,etc.
A2:Minimum：trial order is also available,but with sample price.
Q5:what’s your Lead time?
A: As the General size have stock with fast delivery,the customized size need to negotiate mostly
within 15days.
